E 205
Insert For the optimum loading of glasses.
- Suitable for lower baskets U 890 and APFD 220
- For 17 glasses with a diameter of 2.6 inches
- With perforated tray inlay to interrupt the water jet
- Rail height 8 11/16 (220) in (mm)
- The maximum vertical clearance with glasses is 10 11/16 (270) in (mm)
Product details
E 205
EAN 4002511808874 / Article number 67520501D / Material number 03808980
| Fresh-water dishwashers |
- Fresh-water dishwashers
| PG 8041 | |
| PG 8043 | |
| PG 8045 | |
| PG 8055 | |
| PG 8055 U | |
| PG 8056 | |
| PG 8056 U | |
| PG 8057 TD | |
| PG 8057 TD U | |
| PG 8058 | |
| PG 8058 U | |
| PG 8059 | |
| PG 8059 U | |
| PG 8060 | |
| PG 8061 | |
| PG 8061 U | |
| PG 8096 | |
| PG 8096 U | |
| PG 8099 | |
| PG 8099 U | |
| PFD 400 | |
| PFD 400 U | |
| PFD 401 | |
| PFD 401 U | |
| PFD 402 | |
| PFD 402 U | |
| PFD 404 | |
| PFD 404 U | |
| PFD 405 | |
| PFD 405 U | |
| PFD 407 | |
| PFD 407 U | |
| PFD 408 U |
- PG 8041
- PG 8043
- PG 8045
- PG 8055
- PG 8055 U
- PG 8056
- PG 8056 U
- PG 8057 TD
- PG 8057 TD U
- PG 8058
- PG 8058 U
- PG 8059
- PG 8059 U
- PG 8060
- PG 8061
- PG 8061 U
- PG 8096
- PG 8096 U
- PG 8099
- PG 8099 U
- PFD 400
- PFD 400 U
- PFD 401
- PFD 401 U
- PFD 402
- PFD 402 U
- PFD 404
- PFD 404 U
- PFD 405
- PFD 405 U
- PFD 407
- PFD 407 U
- PFD 408 U
| Insert for glasses |
- Insert for glasses
| Material | Wire, rilsan-coated |
| Color | White |
| Number of rows | 2 |
| Rail height in mm | 8 11/16 (220) |
| Maximum vertical clearance in mm | 10 11/16 (270) |
| For use in lower basket | APFD 220 U 890 |
- Material
- Wire, rilsan-coated
- Color
- White
- Number of rows
- 2
- Rail height in mm
- 8 11/16 (220)
- Maximum vertical clearance in mm
- 10 11/16 (270)
- For use in lower basket
- APFD 220U 890
| Glasses up to max. Ø 2 5/8" (66 mm) [number] | 17 |
- Glasses up to max. Ø 2 5/8" (66 mm) [number]
- 17
| Number of phases | 0 |
| Voltage in V | 0-0 |
| Frequency in Hz | 0-0 |
| Total rated load in kW | 0-0 |
| Fuse rating in A | 0-0 |
- Number of phases
- 0
- Voltage in V
- 0-0
- Frequency in Hz
- 0-0
- Total rated load in kW
- 0-0
- Fuse rating in A
- 0-0
| External dimensions, net height in inches | 8 3/4 (221) |
| External dimensions, net width in inches | 9 5/8 (243) |
| External dimensions, net depth in inches | 19 1/2 (494) |
| External dimensions, gross height in inchesi | 9 1/16 (230) |
| External dimensions, gross width in inchesi | 19 15/16 (505) |
| External dimensions, gross depth in inchesi | 9 7/8 (250) |
| Net weight in lbs | 3 (1.4) |
| Gross weight in lbsi | 4 (1.8) |
- External dimensions, net height in inches
- 8 3/4 (221)
- External dimensions, net width in inches
- 9 5/8 (243)
- External dimensions, net depth in inches
- 19 1/2 (494)
- External dimensions, gross height in inchesi
- 9 1/16 (230)
- External dimensions, gross width in inchesi
- 19 15/16 (505)
- External dimensions, gross depth in inchesi
- 9 7/8 (250)
- Net weight in lbs
- 3 (1.4)
- Gross weight in lbsi
- 4 (1.8)
