PWA 8672 [U DS5 2AC208V/60HZ]
Washer With liquid dispensing and AutoOpen function.
- Shortest program runtime: 25 min
- Capacity/cycle: e.g., 12 full-size cassettes (8 x 11 x 1.25 inch)
- Performance/cycle: e.g., 12 Large sized Cassettes, 24 medium sized cassettes
- Maximum user convenience with M Touch Flex full-touch color display
- Connectivity as standard via Wi-Fi
Voltage:
2 AC 208V 60HZ 30 A
Product benefits
AutoOpen function* Quick drying: At the end of the reprocessing program the machine door opens automatically. Crevice-free wash cabinet Perfect hygiene through optimized geometry and laser welding. Spray arm monitoring Reliable cleaning performance thanks to the monitoring of the rotation speed of the spray arm. Spray arm pressure monitoring The wash pressure is monitored for perfect cleaning results. How-to sequences This reduces downtimes and ensures smooth processes. M Touch Flex controls Use all programs and machine functions conveniently with a touch of a fingertip on the plain text touch display. Variable-speed heater pump Only with Miele Professional: The wash pressure is perfectly tailored to the changing requirements. Integrated water softener The integrated water softener ensures optimum cleaning effectiveness. AutoOpen function* Quick drying: At the end of the reprocessing program the machine door opens automatically. Miele MOVE Connect (option) Compatible with the optional Miele MOVE Connect software solution for networking the appliance. Wi-Fi interface Wi-Fi for flexible and secure communication Crevice-free wash cabinet Perfect hygiene through optimized geometry and laser welding. Heater elements outside the wash cabinet A plus for hygiene: The heating elements are installed outside the wash cabinet. Easy-to-service construction Short service times thanks to maintenance-optimized machine design. Spray arm monitoring Reliable cleaning performance thanks to the monitoring of the rotation speed of the spray arm. Spray arm pressure monitoring The wash pressure is monitored for perfect cleaning results. Process documentation Safety through the clear documentation of all the reprocessing steps. Waterproof System (WPS) Protection against flooding: In the event of problems, the system stops water intake automatically. How-to sequences This reduces downtimes and ensures smooth processes. M Touch Flex controls Use all programs and machine functions conveniently with a touch of a fingertip on the plain text touch display. Clear text display Everything at a glance: The display shows everything as clear text in the country-specific language. Convenient suction lance DC5 Dispenser module for 5 L canisters, for automatic dispensing of liquid media, with fill level detection. Flexible language selection The language setting can be changed at any time – even during a cleaning process. Process approval directly via the display Batch control processes can be approved directly on the machine, simplifying many everyday processes. AutoClose* A light touch is all it takes: With AutoClose the door closes on its own. Large selection of components Flexible and comprehensive components for optimum cleaning performance and a variety of reprocessing options. Patented, in-door salt container Ergonomic convenience: The in-door salt container is particularly easy to fill. Can be built under a worktop The machine can be easily integrated under a worktop.
Product benefits
- Highlights
- Cleaning results
- Connectivity
- Quality
- Safety
- User convenience
Highlights
Cleaning results
Connectivity
Quality
Safety
User convenience

AutoOpen function*
Convenient drying support
Quick drying: At the end of the reprocessing program the machine door opens automatically.

Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Product details
PWA 8672 [U DS5 2AC208V/60HZ]
EAN 4002516884781 / Article number 62867202NAM / Material number 12800830
| Model | Freestanding appliance, can be built-under, slim |
| Line | ExploreLine |
| Outer casing | Stainless Steel |
| Control panel color | Black |
| lid | Without lid |
| Can be built-under | |
| Number of wash levels | 2 |
| AutoClose – Automatic door lock | |
| Buzzer, acoustic signal at end of program | |
| Easy-to-service construction |
| Surgical saliva extractors per cycle [number] | 44 |
| Lumened instruments per cycle [number] | 44 |
| Transmission instruments per cycle [number] | 44 |
| Large Cassettes (8x11”) | 12 |
| Medium Cassettes (8x6”) | 24 |
| Mesh trays (32 x 203 x 279 mm) (W x H x D) per batch [number] | 12 |
- Surgical saliva extractors per cycle [number]
- 44
- Lumened instruments per cycle [number]
- 44
- Transmission instruments per cycle [number]
- 44
- Large Cassettes (8x11”)
- 12
- Medium Cassettes (8x6”)
- 24
- Mesh trays (32 x 203 x 279 mm) (W x H x D) per batch [number]
- 12
| Circulation pump, Qmax in gal/min (l/min) | 132.1 (500) |
| Shortest program runtime in min | 25 |
| Maximum final rinse temperature in °F (in °C) | 158 (70) |
| Usable wash cabinet volume in l | 5.12 (145) |
| Tested operating hoursi | 15000 |
- Circulation pump, Qmax in gal/min (l/min)
- 132.1 (500)
- Shortest program runtime in min
- 25
- Maximum final rinse temperature in °F (in °C)
- 158 (70)
- Usable wash cabinet volume in l
- 5.12 (145)
- Tested operating hoursi
- 15000
| Miele MOVE Connect (option) |
- Miele MOVE Connect (option)
| Control system | M Touch Flex |
| Process approval directly via the display | |
| Max. delay start in h | 24 |
| Programmability | programmable |
| Programs [number] | 5 |
| Free program slots [number] | 5 |
| Time-left display | |
| Program-cycle display | |
| Choice of display languages |
- Control system
- M Touch Flex
- Process approval directly via the display
- Max. delay start in h
- 24
- Programmability
- programmable
- Programs [number]
- 5
- Free program slots [number]
- 5
- Time-left display
- Program-cycle display
- Choice of display languages
| Electrical connection | 3 AC 208V 60HZ |
| Electric heater rating in kW | 5.4 |
| Total rated load in kW | 6.2 |
| Fuse rating in A | 20 |
- Electrical connection
- 3 AC 208V 60HZ
- Electric heater rating in kW
- 5.4
- Total rated load in kW
- 6.2
- Fuse rating in A
- 20
| Cold water [number] | 1 |
| Hot water [number]i | 1 |
| Required flow pressure in kPai | 200-1000 |
| Maximum delivery head for drain pump in inches (cm) | 39 3/8 (100) |
| Integrated water softener | |
| Maximum water hardness (cold water/hot water) in gpg (mmol/l) | 62.595 (10.7) |
| Drain pump [DN] | 0.866 (22) |
| Water protection systemi | Waterproof system |
- Cold water [number]
- 1
- Hot water [number]i
- 1
- Required flow pressure in kPai
- 200-1000
- Maximum delivery head for drain pump in inches (cm)
- 39 3/8 (100)
- Integrated water softener
- Maximum water hardness (cold water/hot water) in gpg (mmol/l)
- 62.595 (10.7)
- Drain pump [DN]
- 0.866 (22)
- Water protection systemi
- Waterproof system
| External dimensions, net height in inches | 32 5/16 (820) |
| External dimensions, net width in inches | 23 9/16 (598) |
| External dimensions, net depth in inches | 23 9/16 (598) |
| External dimensions, gross height in inchesi | 36 1/4 (920) |
| External dimensions, gross width in inchesi | 26 7/16 (670) |
| External dimensions, gross depth in inches (mm)i | 29 3/16 (740) |
| Wash cabinet, usable height in inches | 20 1/2 (520) |
| Wash cabinet, usable width in inches | 20 7/8 (530) |
| Wash cabinet, depth of upper basket in inches | 18 11/16 (474) |
| Wash cabinet, depth of lower basket in inches | 20 1/2 (520) |
| Net weight in lbs | 149.914 (68) |
| Gross weight in lbsi | 169.756 (77) |
| Maximum floor load in N/m²i | 1220 |
- External dimensions, net height in inches
- 32 5/16 (820)
- External dimensions, net width in inches
- 23 9/16 (598)
- External dimensions, net depth in inches
- 23 9/16 (598)
- External dimensions, gross height in inchesi
- 36 1/4 (920)
- External dimensions, gross width in inchesi
- 26 7/16 (670)
- External dimensions, gross depth in inches (mm)i
- 29 3/16 (740)
- Wash cabinet, usable height in inches
- 20 1/2 (520)
- Wash cabinet, usable width in inches
- 20 7/8 (530)
- Wash cabinet, depth of upper basket in inches
- 18 11/16 (474)
- Wash cabinet, depth of lower basket in inches
- 20 1/2 (520)
- Net weight in lbs
- 149.914 (68)
- Gross weight in lbsi
- 169.756 (77)
- Maximum floor load in N/m²i
- 1220
| 1 door dispenser for rinse aid | |
| 1 dispenser pump for liquid cleaning agent | |
| 1 dispenser pump for neutralizing agent | |
| Suction wand for media canisters 10–20 L (optional) | |
| Convenient suction wand DC5 | |
| Volume-flow control | |
| Spray pressure monitoring | |
| Spray arm monitoring | |
| How-to sequences | |
| Interface for process documentation (optional) | |
| Multi-component filter system | |
| Variable-speed heating pump | |
| Load carrier – direct coupling | |
| AutoOpen | |
| Door salt container | |
| Optical interface for Customer Service | |
| Wash cabinet seamlessly welded using laser technology | |
| Heating elements outside the wash cabinet | |
| Wash cabinet made of high-quality stainless steel (1.4301/304) | |
| Extensive components (option) |
- 1 door dispenser for rinse aid
- 1 dispenser pump for liquid cleaning agent
- 1 dispenser pump for neutralizing agent
- Suction wand for media canisters 10–20 L (optional)
- Convenient suction wand DC5
- Volume-flow control
- Spray pressure monitoring
- Spray arm monitoring
- How-to sequences
- Interface for process documentation (optional)
- Multi-component filter system
- Variable-speed heating pump
- Load carrier – direct coupling
- AutoOpen
- Door salt container
- Optical interface for Customer Service
- Wash cabinet seamlessly welded using laser technology
- Heating elements outside the wash cabinet
- Wash cabinet made of high-quality stainless steel (1.4301/304)
- Extensive components (option)
| IP safety class according to EN 60529: IP 21 | |
| EN 61010-1 | |
| EN 61010-2-040 | |
| EU medical device class IIb | |
| FDA, Health Canada, Medical Device class II |
- IP safety class according to EN 60529: IP 21
- EN 61010-1
- EN 61010-2-040
- EU medical device class IIb
- FDA, Health Canada, Medical Device class II
